S7 FEATURES
NEW SEALED & DUST-PROOF GRINDING HEAD
Longer service life and less maintenance.
- Completely redesigned chain-driven planetary drive
- New stronger timing belt
- Upgraded shafts, seals and bearings
- New lighter timing pulleys for better power transmission
- New 2-piece aluminum main belt housing with belt inspection cover for longer belt life and less maintenance
Motor Power: 10 hp / 7.5 kW. Also offered with 15 hp – see L25LS7
Voltage: 1 or 3 phase, 200-240V, 30 Amp max;
European Model: 3 phase, 380-400V, 15 Amp – L25ES7
Weight: 871 lbs / 395 kg
Grinding Pressure: 329-514 lbs / 149-233 kg
Integrated weights with 4 positions
Heads: 3 x 9 inch / 225-mm (left rotation)
Tool Holder RPM: 400-1100
Camlock E250
NEW FRAME DESIGN
Better control, easier tool changes, and less vibrations.
- New weights for faster position change
- Redesigned frame allowing easier tool changes
- New ergonomic handle design – faster adjustability and more positions
- Rubber bushing used at head attachment points – less vibrations for user
- Water tank cap
- Internal storage compartment
- LED lights with magnetic attachment
